300/11 Black Potting and Encapsulation Epoxy Resin – 10 Gallon Kit

$966.00

Same Day Shipping: Orders Placed Before 2pm PT M-F

Canadian Customers click here for shipping details.

AeroMarine Epoxy #300/11 is a high performance epoxy used for the manufacturing and repair of aircraft, boats, sporting goods, and industrial products.
It is available in a clear amber color.
Available in black and clear amber.
100% solid resin system.
Formulated for ease in handling.
Simple 1:1 mix ratio
Dielectric strength of 450 volts per mil (.001″)
10 gallon kit.

DESCRIPTION
HOW-TO
SHIPPING & RETURNS
PURCHASE NOW
TDS

PRODUCT DESCRIPTION

Features:

Long work life
Room temperature cure
Low viscosity
Simple, noncritical 1:1 mix ratio

Specifications:

Viscosity: 3000cps maximum
Color: Clear Amber
Work life: 45-60 minutes@70F
Cure time: 24 hours@70F
Thermal Conductivity: 4.2 BTU/hr/ft2/ºF/in.
Shear strength: 2500psi
Tensile Strength 8000 psi
Flexural strength: 12,800psi
Dielectric Constant 3.5 @ 1 KHz @ 23°C (73°F)
Volume Resistivity 4.1 x 1014 ohm-cm
Modulus of elasticity: 5.7 x 10^6
Dielectric Strength: 450 volts per mil (.001”)

HOW-TO:

Mixing:

Mix the resin and hardener in equal parts by weight or volume. AeroMarine Products Epoxy #300/11 begins to gel in about 45 minutes, depending on the size of the batch and the temperature.
Apply to clean dry surfaces. Cleaning with acetone, alcohol is recommended.
Sanding or abrading surfaces generally increases bond strength.
Turn the container upside down every 7 days to maintain color dispersion and shake resin vigorously for 2 minutes before using.

Tips:

Never mix less than about 3 ounces of product. When manufacturers design and test
their resins they normally write the specifications for 100 gram batches, which is about 3
ounces. There are two bad things that can happen when mixing a smaller batch. Since the
sample is small, it is much more difficult to get the mix ratio correct. Also, these mixtures are
exothermic, meaning that they generate heat in order to cure. A tiny batch does not generate enough heat to cure the resin properly.
Avoid mixing a large batch- At least until you are familiar with the product. The larger the
batch, the more exotherm or heat is generated in the cure cycle. If you are casting a large
part, consider mixing small batches to make the process more manageable. Thickness of
the pour also affects the exotherm and cure speed. 3/8” is about the maximum thickness to
pour most epoxies.
Consider mixing everything twice- especially if you are a beginner. Mix the two components together, then transfer the mixture to another container and mix them again. The theory is that the liquids clinging to the sides and bottom of the containers don’t get mixed well. By transferring the mixture to another container, you are assured that everything is well mixed.

Mix in plastic containers. Paper cups contain moisture which may adversely affect the
resin, especially polyurethanes. Avoid waxed paper cups.
Avoid mixing with drill motors. Mixing with an electric drill can cause a few problems. Frequently they don’t get into every corner of the mixing container. Also, if they spin too fast
they can generate friction in the resin causing it to exotherm out of control resulting in premature curing. Powered mixing also can generate a lot of air bubbles.
Storage- Epoxy hardeners usually last forever. Epoxy resins; however, tend to freeze even
at fairly high temperatures, sometimes into the fifty degree Fahrenheit range. If allowed to
freeze, “epoxy ice” can form in the container. It usually looks like swirls of white stuff
suspended in the resin. It can be reconstituted by warming at 120F for a couple of hours- or you can use the “non-ice” part of the epoxy.
Spraying- Epoxies don’t spray well- they tend to run off vertical surfaces when sprayed.
Clean-up- Aerosol carburetor cleaner to clean up spills and messes. Otherwise just about
any solvent will work, including acetone, toluene, xylene, and lacquer thinner. Avoid
regular paint thinner (mineral spirits). To clean hands use “Fast Orange” hand cleaner
available in automotive supply stores.
Thinning- Thinning is not recommended for most applications. There are very few
exceptions. The most common acceptable use of a thinner is when using epoxy to
penetrate wood. In this case about 10% is a good amount of thinner to use. Keep in mind
that thinners are flammable, so spread the epoxy promptly after thinning to keep the
exothermic heat from building up.
Test- Always make a test to determine the feasibility of your process. There are many
unforeseen factors that can affect the outcome of your project. Running a controlled test
may be inconvenient, but it can make the “Learning Curve” of processing these products
much easier.

Technical Data Sheets (TDS)

Download

SHIPPING AND RETURNS

Shipping
Please contact us at 800-858-5990 for shipping.

Returns
We do not accept returns for this item.

**shipping estimates may vary based on product selection and destination and a tracking code will be sent after checkout.

Canadian Customers**

If you are ordering from Canada, additional shipping rates and fees may apply. Please contact one of our representatives for more information. Contact us today!
